Automation parts

Designed to be connected to our automations but also to third-party automations after careful compatibility check

Active filters

  • Remote control 433 MHz kit
    433 MHz Remote control kit
    A1V0T40
    • The radio control kit consists of a receiver that plugs directly into MARK series control units without additional wiring or connections and a 3-channel remote control.
    • Receiver: ASK/OAK superheterodyne receiver ensuring high reception reliability and effective operation even in environments with signal interference
    • Capacity for 15 remote control codes
    • Frequency 433.9 MHz
    • Operating temperature -25 to +60°C.
    • Remote control: fixed-code remote with three buttons for open, close, and stop functions
    • Power supply: one 12V 23A lithium battery
    • Radiated power: 0.1 mW
    • Operating temperature: 0 to +60°C.
  • 433 MHz Remote control
    433 MHz Remote control
    A1V0T43
    • Remote control: fixed-code remote with three buttons for open, close, and stop functions
    • Power supply: one 12V 23A lithium battery
    • Radiated power: 0.1 mW
    • Operating temperature: 0 to +60°C.
  • End cap for automatic track
    * End cap for automatic rail
    A1X1390
    • Set of accessories to create casings to fully cover the automation, the supply does not include the sheet metal, to be created by the customer based on our design
    • Hinged opening with lock in opening, for easy maintenance
    • Facilitated cable entry thanks to the pre-drilling of the head
    • Brackets, end caps and screws in AISI-304 stainless steel
    • For doors with a width greater than 2400mm it is advisable to install the A1X1373 support bracket in the center
  • Idle belt unit
    Idle belt unit
    A1X1700
    • Ball bearing idler pinion
    • Material PA6+30%FG RAL 7039
    • Stainless steel shaft and nut
    • Operating temperature -30° +80°C
  • Idle chain 1/2 " unit
    idle chain 1/2 " unit
    A1X1750
    • Ball bearing idler pinion
    • Material PA6+30%FG RAL 7039
    • Stainless steel shaft and nut
    • Operating temperature -30° +80°C
  • Drive shaft
    K Drive shaft
    A1X1800
    • Motor shaft set
    • Stainless steel material
    • Complete with tabs, washers, nut and seeger
  • HTD8 Z24 motor pinion
    HTD8 Z24 motor pinion
    A1X1812
    • Tested pinion with high resistance and rust resistance
    • Material PA6 + 30% FG RAL 7039
    • Operating temperature -30 ° + 80° C
  • 1/2" Z16 Chain motor pinion
    1/2" Z16 Chain motor pinion
    A1X1872
    • Tested chain pinion with high resistance and rust resistance
    • Material PA6 + 30% FG RAL 7039
    • Operating temperature -30 ° + 80° C
